3292W-1-103LF

BOURNS  3292W-1-103LF  电位器, 0.5W, 10K

0.5W，1/2W PC 引脚 通孔 微调电位计 金属陶瓷 匝 顶部调节

艾睿:
Infrequently adjust the resistor value for your circuit with this 3292W-1-103LF potentiometer from Bourns. This product has a resistance value of 10K Ohm. This durable part has a power rating of 0.5 1/2 W. Its temperature coefficient is ±100 ppm/°C. In order to ensure parts aren&s;t damaged by bulk packaging, this product comes in tube packaging to add a little more protection by storing the loose parts in an outer tube. This device is made with cermet technology. The 3292W-1-103LF part has a pin termination style. This product is 9.53 mm long, 11.05 mm tall and 3.81 mm deep. This part has an operating temperature of -65 to 150 °C. It has a tolerance of 10%.

Allied Electronics:
Trimmer; Cermet; Rest 10 Kilohms; PCB; 25 Turns; Pwr-Rtg 0.5W

安富利:
Res Cermet Trimmer 10K Ohm 10% 1/2W 25ElecTurn 2.29mm 9.53 X 3.81 X 11.05mm Pin Thru-Hole Tube

Chip1Stop:
Res Cermet Trimmer 10K Ohm 10% 0.5W1/2W 25ElecTurn 2.29mm 9.53 X 3.81 X 11.05mm Pin Thru-Hole Tube

TME:
Potentiometer: mounting; vertical, multiturn; 10kΩ; 500mW; THT

Verical:
Res Cermet Trimmer 10K Ohm 10% 0.5W1/2W 25ElecTurn 2.29mm 9.53 X 3.81 X 11.05mm Pin Thru-Hole Tube

Newark:
# BOURNS  3292W-1-103LF  Trimmer Potentiometer, Multiturn, 10 kohm, 500 mW, ± 10%, Trimpot 3292 Series, 25 Turns

MASTER:
Res Cermet Trimmer 10K Ohm 10% 0.5W1/2W 25ElecTurn 2.29mm 9.53 X 3.81 X 11.05mm Pin Thru-Hole Tube

Online Components:
Res Cermet Trimmer 10K Ohm 10% 0.5W1/2W 25ElecTurn 2.29mm 9.53 X 3.81 X 11.05mm Pin Thru-Hole Tube

Electro Sonic:
Res Cermet Trimmer 10K Ohm 10% 0.5W1/2W 25ElecTurn 2.29mm 9.53 X 3.81 X 11.05mm Pin Thru-Hole Tube
