3590S-2-104概述
Res Wirewound POT 100KΩ 5% 2W 10Elec/10MechTurn 6.34mm 39.22 X 22.23 X 26.66mm Solder Lug Panel Mount
100k Ohm 1 Gang Linear Panel Mount Potentiometer None 10 Kierros Wirewound 2W Solder Lug
得捷:
POT 100K OHM 2W WIREWOUND LINEAR
艾睿:
Res Wirewound POT 100K Ohm 5% 2W 10Elec/10MechTurn 6.34mm 39.22 X 22.23 X 26.66mm Solder Lug Panel Mount
Electro Sonic:
Res Wirewound POT 100K Ohm 5% 2W 10Elec/10MechTurn 6.34mm 39.22 X 22.23 X 26.66mm Solder Lug Panel Mount
3590S-2-104中文资料参数规格
技术参数
额定电压DC 500 V
容差 ±5 %
额定功率 2 W
电阻 100 kΩ
阻值偏差 ±5 %
封装参数
安装方式 Solder Lug, Panel
封装 Round - 0.875" Dia x 0.732" H 22.23mm x 18.60mm
外形尺寸
长度 18.6 mm
直径 22.2 mm
封装 Round - 0.875" Dia x 0.732" H 22.23mm x 18.60mm
物理参数
工作温度 -40℃ ~ 125℃
温度系数 ±50 ppm/℃
其他
产品生命周期 Obsolete
包装方式 Bulk
符合标准
RoHS标准 Non-Compliant
含铅标准 Contains Lead
在线购买3590S-2-104
型号： 3590S-2-104
制造商：
Bourns J.W. Miller
伯恩斯
描述：Res Wirewound POT 100KΩ 5% 2W 10Elec/10MechTurn 6.34mm 39.22 X 22.23 X 26.66mm Solder Lug Panel Mount
