3-87215-0

集管和线壳 UNSHRD VERT DUAL 60

60 MODII HDR DRST UNSHRD .100

Product Highlights

Header

Header Type = Standard

Number of Rows = Dual

Number of Positions = 60

Mating Post Length = 8.08 mm

得捷:
CONN HEADER VERT 60POS 2.54MM

贸泽:
集管和线壳 UNSHRD VERT DUAL 60

艾睿:
TE Connectivity brings you their unshrouded 3-87215-0 header connector, an important safety tool for protecting your electronic components from accidental damage. This HDR connector&s;s 60 contacts that are made out of phosphor bronze and plated with gold over nickel. This is a 2-row connector. Its pitch is 2.54 mm. It has a header type gender. It has a straight body orientation. This device has a maximum current rating of 3 A/contact. This connector has an operating temperature of -65 to 105 °C. This product is 75.79 mm long, 10.36 mm tall and 4.87 mm deep. 3-87215-0 is housed in black thermoplastic. It uses the solder termination method.

Verical:
Conn Unshrouded Header M 60 POS 2.54mm Solder ST Top Entry Thru-Hole Carton

MASTER:
ASSEMBLY, MOD II, HEADER, DOUBLE ROW, .100 X .100 CL. VERTICAL, .025 SQUARE POSTS

Powell:
.100 inch AMPMODU Headers

Online Components:
60 MODII HDR DRST UNSHRD .100

Electro Sonic:
60 MODII HDR DRST UNSHRD .100
