集管和线壳 05P MTA100 HDR ASSY F/L LF
针座 通孔 5 位置 0.100"(2.54mm)
得捷:
CONN HEADER VERT 5POS 2.54MM
贸泽:
集管和线壳 05P MTA100 HDR ASSY F/L LF
艾睿:
This 3-647609-5 connector from TE Connectivity is used for jumper posts to support physical configuration options on printed circuit boards. It has a 6.6 body orientation. In order to ensure parts aren&s;t damaged by bulk packaging, this product comes in tube packaging to add a little more protection by storing the loose parts in an outer tube. This product is 2.5Typ mm long. It uses the cmos termination method.
Chip1Stop:
Conn Wire to Board HDR 5 POS 2.54mm Solder ST Thru-Hole
Verical:
Conn Wire to Board HDR 5 POS 2.54mm Solder ST Top Entry Thru-Hole Bag/Box
Electro Sonic:
05P MTA100 HDR ASSY F/L LF
触点数 5
触点电镀 Tin
绝缘电阻 5000 MΩ
排数 1
方向 Vertical
易燃性等级 UL 94 V-0
针脚数 5
额定电流Max 5A/触头
工作温度Max 105 ℃
工作温度Min -55 ℃
额定电压Max 250 VAC
额定电压 250 VAC
接触电阻Max 6 mΩ
安装方式 Through Hole
高度 10.55 mm
外壳颜色 Black
颜色 Black
触点材质 Copper Alloy
工作温度 -55℃ ~ 105℃
外壳材质 Polyester
产品生命周期 Active
包装方式 Bag, Box
制造应用 通用, Signal
RoHS标准 RoHS Compliant
含铅标准 Lead Free
ELV标准 Compliant
