31005103

METZ CONNECT  31005103  线至板接线端子, 3 路, 250 V, 24 A, 22 AWG, 12 AWG, 2.5 mm²

The is a 3-pole black wire-to-board Screw Terminal Block with through-hole 45° direction of connection and wire protector. It is fittable without loss of poles and has 5mm centreline. It has nickel-tin-plated CuZn terminal with tin-plated CuSn wire protector, zinc-chromate VI screw surface and PA 66 insulation.

.

IP20 Protection

.

CTI600 Insulating material class

.

-40 to 105°C Operating temperature range
