315-93-164-41-001000

Conn SIP Socket Strip SKT 64POS 2.54mm Solder ST Thru-Hole

Low Profile Solder Tail Socket

Accepts .015"- .025" 0,38 - 0,635 mm dia leads

Single Row .100" 2,540mm Pitch Through Hole

得捷:
CONN STRIP SOCKET 64POS LO PRO

艾睿:
Safety is an important concern when designing electronic devices. Mill-Max Mfg. Corp.&s;s sip socket strip 315-93-164-41-001000 header connector helps protect your equipment from accidental shortages. This SKT connector&s;s 64 contacts that are made out of beryllium copper alloy and plated with gold over nickel. It has a socket type gender. Its pitch is 2.54 mm. This is a 1-row connector. It has a straight body orientation. It has a maximum voltage rating of 150 VDC|100VAC. This device has a maximum current rating of 3 A. 315-93-164-41-001000 is housed in black polychlorinated terphenyl. This connector has an operating temperature of -55 to 125 °C. This product is 162.56 mm long, 3.1 mm tall and 2.54 mm deep. It uses the solder termination method.

Allied Electronics:
IC & Component Sockets 64 POS LOW PRO .1"

Chip1Stop:
Conn SIP Socket Strip SKT 64 POS 2.54mm Solder ST Thru-Hole

Verical:
Conn Socket Strip SKT 64 POS 2.54mm Solder ST Thru-Hole
