JOHANSON DIELECTRICS 302S43W102KV4E 多层陶瓷电容器, 表面贴装, 1000 pF, ± 10%, X7R, 3 kV, 1812 [4532 公制]
1000 pF ±10% 3000V（3kV） 陶瓷器 X7R 1812（4532 公制）
得捷:
CAP CER 1000PF 3KV X7R 1812
立创商城:
1nF ±10% 3kV
e络盟:
多层陶瓷电容器, 表面贴装, 1000 pF, 3 kV, 1812 [4532 公制], ± 10%, X7R
艾睿:
This 302S43W102KV4E multilayer ceramic capacitor from Johanson offers high stability and low losses for resonant circuit applications. It can withstand a voltage of 3000 VDC. This MLCC capacitor has a maximum operating temperature of 125 °C. This component will be shipped in tape and reel packaging for effective mounting and safe delivery. This product is 4.57 mm long, 2.8Max mm tall and 3.17 mm deep. Its capacitance value is 0.001uF. It has a tolerance of 10%.
Verical:
Cap Ceramic 0.001uF 3000V X7R 10% Pad SMD 1812 125C T/R
Newark:
Multilayer Ceramic Capacitor, 1000 pF, 10%, X7R, 3 kV, 1812 [4532 Metric]
RfMW:
HI V MLCC 1812,1000pF,±10%,3KV
额定电压DC 3.00 kV
电容 1000 pF
容差 ±10 %
电介质特性 X7R
产品系列 TANCERAM
工作温度Max 125 ℃
工作温度Min -55 ℃
额定电压 3 kV
安装方式 Surface Mount
引脚数 2
封装公制 4832
封装 1812
长度 4.5 mm
宽度 3.2 mm
高度 2.8 mm
封装公制 4832
封装 1812
材质 X7R/-55℃~+125℃
工作温度 -55℃ ~ 125℃
产品生命周期 Active
包装方式 Cut Tape CT
最小包装 1000
制造应用 工业, 通用, Communications & N, 电源管理, Communications & Networking, Commercial, Industrial, Lighting, , 通信与网络, Power Management, 商业
RoHS标准 RoHS Compliant
含铅标准
REACH SVHC标准 No SVHC
REACH SVHC版本 2015/12/17
