Littelfuse 396 系列Littelfuse 396 系列是时滞类型的熔丝。 适用于以下应用,如电池充电器、消费电子产品、电源和工业控制器。### 认可UL### 印刷电路板线端 - 超微型### 印刷电路板线端所有熔丝均为热塑聚酰胺主体
396 系列
Littelfuse 396 系列是时滞类型的熔丝。 适用于以下应用,如电池充电器、消费电子产品、电源和器。
### 认可
UL
欧时:
Littelfuse 5A 径向 带引线的 PCB 固定熔断器 39615000000, T熔断速度, 125V, 8.5mm长, 4mm宽, 8mm高
艾睿:
Be protected by adding a subminiature 39615000000 fuse developed by Littelfuse. Its maximum power dissipation is 475 W. This device has a current rating of 5. This device has a maximum power dissipation of 475 W. This fuse has an operating temperature range of -40 °C to 85 °C. It has 2 terminals. The 39615000000 fuse has a radial termination style. The maximum AC voltage rating is 125 VAC. This product is 8.5 mm long, 8Max mm tall and 4Max mm deep.
富昌:
396 Series Time Lag 125 V 5 A 8.5 x 4 x 8 mm Radial Lead Fuse
Chip1Stop:
Fuse Subminiature Slow Blow Acting 5A 125V Radial 8.5 X 4 X 8mm Ammo Pack
TME:
Fuse: fuse; time-lag; 5A; 125VAC; TE5
Newark:
# LITTELFUSE 39615000000 Fuse, PCB Leaded, 5 A, 125 VAC, TE5 Series, Time Delay, Radial Leaded
额定电压DC 125 V
额定电压AC 125 V
额定电流 5 A
易燃性等级 UL 94 V-0
工作温度Max 85 ℃
工作温度Min -40 ℃
额定电压 125 V
额定电压AC Max 125 V
安装方式 Through Hole
引脚数 2
封装 Radial, Box
长度 8.5 mm
宽度 4 mm
高度 8 mm
脚长度 18.8 mm
封装 Radial, Box
电源线长度 18.8 m
颜色 Brown
工作温度 -40℃ ~ 85℃
产品生命周期 Active
包装方式 Tape
RoHS标准 RoHS Compliant
含铅标准 Lead Free
REACH SVHC标准 No SVHC
