38.52.7.048.0050

线圈电压 48 VDC

工作温度 -40℃ ~ 70℃

Type of relay interface

Contacts configuration DPDT

Rated coil voltage 48V DC

Operating current max. 8A

AC contacts rating @R 8 A / 250 VAC

DC contacts rating @R 8 A / 30 VDC

Switched voltage max 400V AC, max 220V DC

Mounting DIN

Leads screw terminals

Relay variant Relay set

Relay series 38.52

Operating temperature -40...70°C

Body dimensions 89.7 x 14 x 77.1mm

IP rating IP20

Indication LED

Dimensions see

Schematic diagram see

RoHS标准 RoHS Compliant

数据手册
