Relay SSR 12mA 32V DC-IN 10A 280V AC-OUT 4Pin
固态 SPST-NO（1 Form A） Hockey Puck
艾睿:
Relay SSR 12mA 32V DC-IN 10A 280V AC-OUT 4-Pin
Allied Electronics:
PM IP00 400Hz 280VAC/10A, 3-32V In, ZC
Chip1Stop:
Relay SSR 20mA 32V DC-IN 10A 280V AC-OUT 4-Pin
Verical:
Relay SSR 12mA 32V DC-IN 10A 280V AC-OUT 4-Pin
MASTER:
SOLID STATE RELAY 24-280 V - PM IP00 400Hz 280VAC/10A,3-32V In,ZC
Online Components:
SOLID STATE RELAY 24-280 V - PM IP00 400Hz 280VAC/10A,3-32V In,ZC
Electro Sonic:
SOLID STATE RELAY 24-280 V - PM IP00 400Hz 280VAC/10A,3-32V In,ZC
输出电流 10000 mA
负载电流 10 A
输入电流 12 mA
隔离电压 4000 v
输入电压Max 32 V
输入电压Min 3 V
输出电压Max 280 V
输入电流Min 20 mA
负载电流Min 150 mArms
工作温度Max 80 ℃
工作温度Min -40 ℃
输入电压 32 V
安装方式 Screw, Panel
引脚数 4
封装 Hockey Puck
高度 23 mm
封装 Hockey Puck
产品生命周期 Active
包装方式 Bulk
RoHS标准 RoHS Compliant
含铅标准 Lead Free
ECCN代码 EAR99
HTS代码 8536490080
