4606X-101-681LF

BOURNS  4606X-101-681LF  电阻网络, 680R

5 总线器

70°C 时功率 | 0.2W（单个），0.75W（总体）

---|---

最大工作电压 | 100V 直流

尺寸（长 x 宽 x 高） | 15.19 x 2.49 x 5.08mm

引线间距 | 2.54mm

电阻容差 | ±2 %

温度系数 | ±100 ppm/°C

温度系数记录 | ±50 ppm/°C

工作温度 | -55°C → +125°C

得捷:
RES ARRAY 5 RES 680 OHM 6SIP

欧时:
Bourns 4600X 系列 680Ω 5电阻 排阻 4606X-101-681LF, ±2%容差, 总线, 额定0.75W, SIP 封装

立创商城:
680Ω ±2%

e络盟:
固定阵列电阻, 680 ohm, 4606X系列, 5 元件, 总线, SIP, 6 引脚

艾睿:
By combining multiple resistors into a single chip, the 4606X-101-681LF resistor array, developed by Bourns, can help you save space and power in your circuit design. This product&s;s 5 resistors have a value of 680 Ohm. Its temperature coefficient is ±100 ppm/°C. This dependable part has a power rating of 0.75 3/4 W and a power rating per resistor of 0.2 1/5 W. It has 6 terminals. This product comes packaged in bulk, so the parts will be stored loosely. It has a tolerance of 2%. This device utilizes thick film technology. This part has an operating temperature of -55 to 125 °C. This product&s;s terminal pitch is 2.54 mm. This product is 15.19 mm long, 5.08 mm tall and 2.49 mm deep. The 4606X-101-681LF part has a pin termination style.

Allied Electronics:
Resistor, Thkfilm, Conf SIP, Rest 680 Ohms, 2%, 100V, 0.75W@70DegC, Bussed

安富利:
Res Thick Film NET 680 Ohm 2% 3/4W ±100ppm/°C BUS Conformal 6-Pin SIP Pin Thru-Hole Bulk

Chip1Stop:
Res Thick Film NET 680 Ohm 2% 0.75W3/4W 100ppm/ C BUS Conformal 6-Pin SIP Pin Thru-Hole Bulk

Verical:
Res Thick Film NET 680 Ohm 2% 0.75W3/4W ±100ppm/C BUS Conformal Coated 6-Pin SIP Pin Thru-Hole Bulk

Newark:
# BOURNS  4606X-101-681LF  RESISTOR NETWORK, 680R

MASTER:
Res Thick Film NET 680 Ohm 2% 0.75W3/4W ±100ppm/°C BUS Conformal Coated 6-Pin SIP Pin Thru-Hole Bulk

Electro Sonic:
Res Thick Film NET 680 Ohm 2% 0.75W3/4W ±100ppm/°C BUS Conformal Coated 6-Pin SIP Pin Thru-Hole Bulk

Win Source:
RES ARRAY 5 RES 680 OHM 6SIP / 680 Ohm ±2% 200mW Power Per Element Bussed 5 Resistor Network/Array ±100ppm/°C 6-SIP
