4609X-101-562LF

SIP，接线 4600R 系列薄型与 DIP 兼容 各种引脚封装增强了设计灵活性 推荐用于松香助焊剂和溶剂清洁剂或免清洗助焊剂过程 ### SIL 封装 - 总线

厚膜保护 SIP，接线 4600R 系列

薄型与 DIP 兼容

各种引脚封装增强了设计灵活性

推荐用于松香助焊剂和溶剂清洁剂或免清洗助焊剂过程

欧时:
厚膜保护 SIP，接线 4600R 系列薄型与 DIP 兼容 各种引脚封装增强了设计灵活性 推荐用于松香助焊剂和溶剂清洁剂或免清洗助焊剂过程

立创商城:
5.6kΩ ±2%

得捷:
RES ARRAY 8 RES 5.6K OHM 9SIP

e络盟:
固定阵列电阻, 5.6 kohm, 4600X Series, 8 元件, 总线, SIP, 9 引脚

艾睿:
Use this 4609X-101-562LF resistor array from Bourns to conserve space by packing multiple resistors into one IC chip. This dependable part has a power rating of 1.13 W and a power rating per resistor of 0.2 1/5 W. This product&s;s 8 resistors have a value of 5.6K Ohm. Its temperature coefficient is ±100 ppm/°C. It has 9 terminals. This product comes packaged in bulk, so the parts will be stored loosely. The 4609X-101-562LF part has a pin termination style. It has a tolerance of 2%. This product&s;s terminal pitch is 2.54 mm. This device is made with thick film technology. This part has an operating temperature of -55 to 125 °C. This product is 22.81 mm long, 5.08 mm tall and 2.49 mm deep.

安富利:
Res Thick Film NET 5.6K Ohm 2% 1.13W ±100ppm/°C BUS Conformal 9-Pin SIP Pin Thru-Hole Bulk

Chip1Stop:
Res Thick Film NET 5.6K Ohm 2% 1.13W ﾂｱ100ppm/C BUS Conformal Coated 9-Pin SIP Pin Thru-Hole Bulk

TME:
Resistor network: X; 5.6kΩ; No.of resistors:8; THT; 0.2W; ±2%; 100V

Verical:
Res Thick Film NET 5.6K Ohm 2% 1.13W ±100ppm/C BUS Conformal Coated 9-Pin SIP Pin Thru-Hole Bulk

MASTER:
Res Thick Film NET 5.6K Ohm 2% 1.13W ±100ppm/°C BUS Conformal Coated 9-Pin SIP Pin Thru-Hole Bulk

Electro Sonic:
Res Thick Film NET 5.6K Ohm 2% 1.13W ±100ppm/°C BUS Conformal Coated 9-Pin SIP Pin Thru-Hole Bulk
