4610X-101-560LF

Res Thick Film NET 56Ω 2% 1.25W 100ppm/℃ BUS Conformal 10Pin SIP Pin Thru-Hole Bulk

is manufactured by Bourns and is categorized in the Resistor Networks, Arrays category. 4610X-101-560LF is described as RES ARRAY 9 RES 56 OHM 10SIP. Perfect Parts is a supplier of Resistors and other Passives.

立创商城:
56Ω ±2%

得捷:
RES ARRAY 9 RES 56 OHM 10SIP

贸泽:
Resistor Networks & Arrays 10pins 56ohms Bussed

艾睿:
Conserve space and power by adopting this 4610X-101-560LF resistor array from Bourns, allowing multiple configurations of resistors to be downsized into an IC. This dependable part has a power rating of 1.25 W and a power rating per resistor of 0.2 1/5 W. Its temperature coefficient is ±100 ppm/°C. This product&s;s 9 resistors have a value of 56 Ohm. It has 10 terminals. This product comes packaged in bulk, so the parts will be stored loosely. This part has an operating temperature of -55 to 125 °C. This product&s;s terminal pitch is 2.54 mm. It has a tolerance of 2%. This device is made with thick film technology. This product is 25.35 mm long, 5.08 mm tall and 2.49 mm deep. The 4610X-101-560LF part has a pin termination style.

安富利:
Res Thick Film NET 56 Ohm 2% 1.25W ±100ppm/°C BUS Conformal 10-Pin SIP Pin Thru-Hole Bulk

Chip1Stop:
Res Thick Film NET 56 Ohm 2% 1.25W 100ppm/ C BUS Conformal 10-Pin SIP Pin Thru-Hole Bulk

Newark:
# BOURNS  4610X-101-560LF  Fixed Network Resistor, Isolated, 56 ohm, 100 V, 9 Elements, Bussed, SIP, 200 mW

Electro Sonic:
Res Thick Film NET 56 Ohm 2% 1.25W ±100ppm/°C BUS Conformal Coated 10-Pin SIP Pin Thru-Hole Bulk
