4116R-1-152LF

BOURNS  4116R-1-152LF  电阻网络,1K5

8 - 隔离器

Bourns 4116R 系列厚膜模制 DIP 与自动插入设备兼容。

卓越的封装完整性

对比背景标记，用于永久性标识

立创商城:
1.5kΩ ±2%

欧时:
### 8 - 隔离电阻器Bourns 4116R 系列厚膜模制 DIP 与自动插入设备兼容。 卓越的封装完整性 对比背景标记，用于永久性标识 70°C 时功率 | 0.25W（单个），2.25W（总体） ---|--- 最大工作电压 | 100V 直流 尺寸（长 x 宽 x 高） | 21.97mm x 7.87mm x 8.40mm 封装 | DIP16 电阻容差 | ±2 % 温度系数 | ±100 ppm/°C 温度系数记录 | ±50 ppm/°C 工作温度 | -55°C → +125°C ### SIL 和 DIL 封装 - 已隔离

艾睿:
Res Thick Film NET 1.5K Ohm 2% 2.25W ±100ppm/°C ISOL Molded 16-Pin DIP Pin Thru-Hole

Allied Electronics:
Resistor; 1.5 Kilohms; 2.25 W @ 70 DegC; 2%; 100 V Max.; 16; 100 ppm/ DegC

Jameco:
Resistor Thick Film Net 1.5k Ohm 2% 2.25 Watt ±100ppm °C Isolated 16-Pin DIP Pin Through Hole

安富利:
Res Thick Film NET 1.5K Ohm 2% 2.25W ±100ppm/°C ISOL Molded 16-Pin DIP Pin Thru-Hole

Chip1Stop:
Res Thick Film NET 1.5K Ohm 2% 2.25W ±100ppm/℃ ISOL Molded 16-Pin DIP Pin Thru-Hole

TME:
Resistor network: Y; 1.5kΩ; No.of resistors:8; THT; 0.28W; ±2%

Verical:
Res Thick Film NET 1.5K Ohm 2% 2.25W ±100ppm/C ISOL Molded 16-Pin DIP Pin Thru-Hole

Newark:
# BOURNS  4116R-1-152LF  Fixed Network Resistor, Thick Film, 1.5 kohm, 100 V, 8 Elements, Isolated, DIP, 250 mW

MASTER:
Res Thick Film NET 1.5K Ohm 2% 2.25W ±100ppm/°C ISOL Molded 16-Pin DIP Pin Thru-Hole

Electro Sonic:
Res Thick Film NET 1.5K Ohm 2% 2.25W ±100ppm/°C ISOL Molded 16-Pin DIP Pin Thru-Hole
