4308R-101-681LF

BOURNS  4308R-101-681LF  电阻阵列, 厚膜, 680Ω, 100V

680 欧姆 ±2% 200mW 每元件功率 总线式 7 器网络，阵列 ±100ppm/°C 8-SIP

得捷:
RES ARRAY 7 RES 680 OHM 8SIP

立创商城:
680Ω ±2%

艾睿:
Looking to save space and power in your circuit design? The 4308R-101-681LF resistor array from Bourns gives you a solution by combining multiple resistors into a single chip. This dependable part has a power rating of 1 W and a power rating per resistor of 0.2 1/5 W. This product&s;s 7 resistors have a value of 680 Ohm. Its temperature coefficient is ±100 ppm/°C. It has 8 terminals. It has a tolerance of 2%. This device utilizes thick film technology. This part has an operating temperature of -55 to 125 °C. The 4308R-101-681LF part has a pin termination style. This product&s;s terminal pitch is 2.54 mm. This product is 19.92 mm long, 4.95 mm tall and 2.16 mm deep.

安富利:
Res Thick Film NET 680 Ohm 2% 1W ±100ppm/°C BUS Molded 8-Pin SIP Pin Thru-Hole

Chip1Stop:
Res Thick Film NET 680 Ohm 2% 1W 100ppm/ C BUS Molded 8-Pin SIP Pin Thru-Hole

Verical:
Res Thick Film NET 680 Ohm 2% 1W ±100ppm/C BUS Molded 8-Pin SIP Pin Thru-Hole

Newark:
# BOURNS  4308R-101-681LF  Fixed Network Resistor, Low Profile, 680 ohm, 100 V, 7 Elements, Bussed, SIP, 200 mW

MASTER:
Res Thick Film NET 680 Ohm 2% 1W ±100ppm/°C BUS Molded 8-Pin SIP Pin Thru-Hole

Electro Sonic:
Res Thick Film NET 680 Ohm 2% 1W ±100ppm/°C BUS Molded 8-Pin SIP Pin Thru-Hole
