4-643813-6

AMP FROM TE CONNECTIVITY  4-643813-6  线至板连接器, 22 AWG, MTA-100系列, 16 触点, 插座, 2.54 mm, IDC / IDT, 1 排

The is a 16-position 1-row closed end Wire-to-Post Connector with tin-plated copper alloy contacts and white GF nylon housing. The receptacle supports IDC termination method to wire/cable and locking lance contact retention. It is applicable to wire/cable. The MTA-100 connector accepts discrete and ribbon cable wire sizes ranging from 22 to 28AWG.

.

With strain relief

.

90° Cable exit angle

.

Moulded ribs on housing do not allow reverse mating

.

Posted connectors for 2 through 19 positions

.

Connectors preloaded with IDC contacts

.

All contacts are slotted for insulation displacement IDC terminal technique

.

Contacts are lubricated for fretting corrosion protection
