4-146285-0

Conn Unshrouded Header HDR 40POS 2.54mm Solder ST Thru-Hole

Connector Header Through Hole 40 position 0.100" 2.54mm

得捷:
CONN HEADER VERT 40POS 2.54MM

贸泽:
Headers & Wire Housings 40 MODII HDR SRST B/

艾睿:
Reduce the possibility of accidentally shorting pins when using a printed circuit board with this unshrouded 4-146285-0 header connector from TE Connectivity. This HDR connector&s;s 40 contacts that are made out of phosphor bronze and plated with gold over nickel. It has a straight body orientation. Its pitch is 2.54 mm. It has a header type gender. This is a 1-row connector. This device has a maximum current rating of 3 A/contact. This product is 101.19 mm long, 8.13 mm tall and 2.34 mm deep. This connector has an operating temperature of -65 to 105 °C. 4-146285-0 is housed in black liquid crystal polymer. It uses the solder termination method.

安富利:
Conn Unshrouded Header HDR 40 POS 2.54mm Solder ST Thru-Hole

Verical:
Conn Unshrouded Header HDR 40 POS 2.54mm Solder ST Thru-Hole Automotive Carton

Newark:
# AMP - TE CONNECTIVITY  4-146285-0  40 MODII HDR SRST B/A .100CL New

MASTER:
HEADER ASSEMBLY, MOD II, BREAKWAY, SINGLE ROW, HIGH TEMPERATURE, VERTICAL W/.025 SQ POSTS, .100 C

Powell:
.100 inch AMPMODU Headers

Electro Sonic:
40 MODII HDR SRST B/A .100CL
