44W 系列 4 mm 正方形 20 kOhm ±10 % 多圈 微调电位器
Not sure what resistance value you need? No problem, applying this potentiometer from BI Technologies TT electronics will allow you to change the resistance in a matter of seconds. This dependable part has a power rating of 0.25 1/4 W. This product has a resistance value of 20K Ohm. Its temperature coefficient is ±100 ppm/°C. In order to guarantee safe delivery and allow for quick mounting of this component after delivery, it will be enclosed in tape and reel packaging during shipment. This part has an operating temperature of -65 to 150 °C. The 44WR20KLFT7 part has a j-hook termination style. It has a tolerance of 10%. This device utilizes cermet technology. This product is 4.83 mm long, 5.31 mm tall and 3.91 mm deep.
额定电压DC 300 V
容差 ±10 %
额定功率 0.25 W
电阻 20 KΩ
阻值偏差 ±10 %
工作温度Max 150 ℃
工作温度Min -65 ℃
安装方式 Surface Mount
封装 Square - 0.190" L x 0.138" W x 0.200" H 4.83mm x 3.51mm x 5.08mm
高度 5.31 mm
封装 Square - 0.190" L x 0.138" W x 0.200" H 4.83mm x 3.51mm x 5.08mm
工作温度 -65℃ ~ 150℃
温度系数 ±100 ppm/℃
产品生命周期 Active
包装方式 Tape & Reel TR
RoHS标准 RoHS Compliant
含铅标准 Lead Free
REACH SVHC版本 2016/06/20
ECCN代码 EAR99
HTS代码 8533408050
