TUSONIX 4701-001LF 滤波器, PI型, SMD
The is a 10A/100V PI-section Circuit Filter with square style, surface mount, SMD terminals. This filter is designed for use near to noise generating components to suppress interference at source. Suitable for radio and telecommunications, disc drives and TV set-top equipment.
- .
- -55 to 125°C Operating temperature range
e络盟:
滤波器, PI型, SMD
Newark:
# TUSONIX 4701-001LF FILTER, PI, SMD, 8200PF, 100V, 10A
额定电压DC 100 V
额定电流 10 A
电容 8200 pF
工作温度Max 125 ℃
工作温度Min -55 ℃
额定电压 100 V
安装方式 Surface Mount
封装 0.336" L x 0.090" W x 0.090" H 8.50mm x 2.29mm x 2.29mm
封装 0.336" L x 0.090" W x 0.090" H 8.50mm x 2.29mm x 2.29mm
产品生命周期 Active
包装方式 Cut Tape CT
制造应用 Computers & Computer Peripherals, 计算机和计算机周边, Signal Processing, 信号处理, 通信与网络, 传感与仪器, Communications & Networking, Sensing & Instrumentation
RoHS标准 RoHS Compliant
含铅标准 Lead Free
REACH SVHC标准 No SVHC
REACH SVHC版本 2015/12/17
