4-644695-0

Conn Unshrouded Header HDR 10POS 2.54mm Solder ST Thru-Hole

10P MTA100 STR HDR RETENTIVE

Product Highlights

Header

10 Positions

Preloaded

Header Gender = Plug

Contact Gender = Pin

得捷:
CONN HEADER VERT 10POS 2.54MM

艾睿:
Support physical configuration options for jumper posts by mounting this unshrouded 4-644695-0 header connector from TE Connectivity. This HDR connector&s;s 10 contacts that are made out of copper alloy and plated with tin. Its pitch is 2.54 mm. It has a header type gender. It has a maximum voltage rating of 250 VAC. This is a 1-row connector. It has a straight body orientation. This device has a maximum current rating of 5 A/contact. It uses the solder termination method. 4-644695-0 is housed in natural polyester. This connector has an operating temperature of -55 to 105 °C. This product is 25.1 mm long, 10.03 mm tall and 2.33 mm deep.

安富利:
Conn Unshrouded Header HDR 10 POS 2.54mm Solder ST Thru-Hole

Verical:
Conn Unshrouded Header HDR 10 POS 2.54mm Solder ST Thru-Hole Bag/Box

Newark:
# AMP - TE CONNECTIVITY  4-644695-0  10P MTA100 STR HDR RETENTIVE New

MASTER:
MTA-100 HEADER ASSEMBLY,NARROW .025 SQUARE STRAIGHT POST WITH RETENTIVE LEGS,TIN PLATED

Online Components:
10P MTA100 STR HDR RETENTIVE

Electro Sonic:
10P MTA100 STR HDR RETENTIVE
