4-1761206-1

Conn SDL RCP 4POS 2.54mm Solder RA Thru-Hole 4 Terminal 1Port

4 SDL SE RCPT ASSY PART SHELD

Product Highlights

Connector

Receptacle

Receptacle Configuration = Standard

Number of Conductors = 4

Keying = D

得捷:
CONN MOD JACK 4P R/A SHLD

艾睿:
You will never drop a call again with this sdl 4-1761206-1 telephone and telecom connector from TE Connectivity. This RCP connector&s;s 4 contacts that are made out of phosphor bronze and plated with gold over nickel. This connector has a single port. It has a right angle body orientation. Its pitch is 2.54 mm. It has a maximum voltage rating of 42VDC|30 VAC. It has a receptacle type gender. This device has a maximum current rating of 1.5 A/contact. It uses the solder termination method. This product is 16.38 mm long, 13.59 mm tall and 16.51 mm deep. 4-1761206-1 is housed in black polyester. This part has an operating temperature of -20 to 80 °C.

Allied Electronics:
SDL ACCESS BUS CONNS; 4 SDL SE RCPT ASSY PART SHELD

安富利:
Conn SDL RCP 4 POS 2.54mm Solder RA Thru-Hole 4 Terminal 1 Port

Chip1Stop:
Conn SDL RCP 4 POS 2.54mm Solder RA Thru-Hole 4 Terminal 1 Port

Verical:
Conn SDL RCP 4 POS 1.27mm Solder RA Thru-Hole 4 Terminal 1 Port

MASTER:
RECEPTACLE ASSEMBLY, 4 POSITION, SIDE ENTRY, SDL

Powell:
SDL Shielded Data Link

Online Components:
RECEPTACLE ASSEMBLY, 4 POSITION, SIDE ENTRY, SDL

Electro Sonic:
4 SDL SE RCPT ASSY PART SHELD
