Cord Plug Assembly; 10A; 250VAC; 10 Megohms Min. @ 500VDC; 2kV @ 50Hz
Connector Plug, 10 A Current Rating, 250 VAC Voltage Rating, 10 Megohms Min. @ 500 VDC Resistance
得捷:
PWR ENT RCPT IEC320-2-2F PANEL
艾睿:
Conn Outlets RCP 3 POS Solder ST Panel Mount 3 Terminal 1 Port
Allied Electronics:
Cord Plug Assembly; 10 A; 250 VAC; 10 Megohms Min. @ 500 VDC; 2 kV @ 50 Hz
安富利:
4787 BACKPLANE OUTLET 10A 70°
Verical:
Conn Outlets RCP 3 POS Solder ST Panel Mount 3 Terminal 1 Port
Newark:
# SCHURTER 4787.1000 Power Entry Connector, IEC Appliance Outlet F, Screw-On Mounting, 4787.1, Receptacle, 250 V, 10 A
MASTER:
4787 BACKPLANE OUTLET 10A 70
Online Components:
4787 BACKPLANE OUTLET 10A 70
Electro Sonic:
4787 BACKPLANE OUTLET 10A 70
CDI:
4787 BACKPLANE OUTLET 10A 70¦
触点数 3
极性 Female
额定电压DC 250 V
额定电压AC 250 V
额定电流 10 A
绝缘电阻 ≥10MΩ @500VDC
易燃性等级 UL 94 V-0
针脚数 3
额定电流Max 15 A
工作温度Max 70 ℃
工作温度Min -25 ℃
额定电压Max 250 VAC
额定电压 250 VAC
安装方式 Panel, Quick Connect, Screw
高度 22 mm
颜色 Black
工作温度 -25℃ ~ 70℃
外壳材质 Thermoplastic
产品生命周期 Active
包装方式 Bulk
RoHS标准 RoHS Compliant
含铅标准 Lead Free
REACH SVHC标准 No SVHC
REACH SVHC版本 2016/06/20
ECCN代码 EAR99
HTS代码 8536698000
