5853 YL001

ALPHA WIRE 5853 YL001 Wire, Hook Up, PTFE, Yellow, 26AWG, 0.142mm², 7 x 34AWG, 1000Ft

The 5853 series products from are hook up wires used for electrical connections. This hook up wire comprises stranded or solid silver plated copper conductor with polytetrafluoroethylene PTFE insulation material. These wire features high temperature, excellent chemical, solvent resistance and excellent electrical properties.

.

Conductor size of 26AWG and 7/34AWG strand size

.

Voltage rating of 600V

.

Available in 100ft, 1000ft lengths

.

MIL-DTL-16878/4 Type E, UL 1213 and NEMA HP3 certified

.

Available in variety of jacket colours

.

Insulation thickness of 0.010inch

.

Operating temperature ranges is -60°C to +200°C MIL and -60°C to +105°C UL
