5262C SL005概述
ALPHA WIRE 5262C SL005 Multipair Unshielded Cable, 2, 24AWG, 0.2mm , 7 x 0.2mm, 100Ft, 30.5m
The is a 100ft 2-pair sunlight resistant high-performance unscreened Cable with stranded tinned copper conductors and premium semi-rigid PVC insulation. It features unique, premium-grade PVC jacket for easier routing of cable in small spaces.
- .
- Xtra-Guard® 1-high performance in a tough PVC cable
- .
- Provides resistance to oils per UL Oil Res I and Class 43
- .
- Nylon ripcord
- .
- 14.1lb Maximum pull tension
- .
- 0.19µH/ft Nominal inductance
- .
- -35 to 105°C Temperature range
5262C SL005中文资料参数规格
技术参数
线规 24 AWG
额定电压DC 300 V
芯数 4
工作温度Max 80 ℃
工作温度Min -20 ℃
额定电压Max 300 VAC
额定电压 300 V
外形尺寸
长度 30.5 m
物理参数
颜色 Slate
绝缘材质 PVC
工作温度 -35℃ ~ 105℃
导体材质 Tinned Copper
外壳材质 PVC
其他
产品生命周期 Active
包装方式 Tape & Reel TR
制造应用 Mining, Oil & Gas, Industrial
符合标准
RoHS标准 RoHS Compliant
含铅标准 Lead Free
REACH SVHC标准 No SVHC
REACH SVHC版本 2015/12/17
在线购买5262C SL005
型号： 5262C SL005
制造商：
Alpha Wire
描述：ALPHA WIRE 5262C SL005 Multipair Unshielded Cable, 2, 24AWG, 0.2mm , 7 x 0.2mm, 100Ft, 30.5m
