ESD 抑制器/TVS 二极管 5kW 64V 5% Bi-Directional
Sleep easy, never worry about surges again with this TVS diode from . Its test current is 1 mA. Its maximum leakage current is 5 μA. Its peak pulse power dissipation is 5000 W. This device"s maximum clamping voltage is 103 V and minimum breakdown voltage is 71.1 V. This TVS diode has an operating temperature range of -55 °C to 150 °C. Tape and reel packaging will encase this product during shipment, in order to ensure safe delivery and enable quick mounting of components.
击穿电压 78.6 V
钳位电压 103 V
测试电流 1 mA
脉冲峰值功率 5000 W
最小反向击穿电压 71.1 V
击穿电压 71.1 V
工作温度Max 150 ℃
工作温度Min -65 ℃
工作结温 -65℃ ~ 150℃
安装方式 Surface Mount
引脚数 2
封装 DO-214AB-2
封装 DO-214AB-2
工作温度 -55℃ ~ 150℃ TJ
产品生命周期 Active
包装方式 Tape & Reel TR
制造应用 通用, 电信
RoHS标准 RoHS Compliant
含铅标准 Lead Free
ECCN代码 EAR99
