5800-121-RC

VW- 1额定热缩管覆盖绕组 VW-1 rated shrink tubing to cover winding

High Current RF Choke Bobbin Core 120uH 10% 1KHz Ferrite 508mA 283mOhm DCR AXL

得捷:
FIXED IND 120UH 700MA 300MOHM TH

艾睿:
This high current rf choke 5800-121-RC leaded inductor from Bourns is constructed on a core with concentric leads on opposite ends of the core. This leaded inductor has a minimum operating temperature of -55 °C and a maximum of 105 °C. Its test frequency is 1K Hz. This product is 17.78 mm long with a diameter of 6.99 mm. It has an inductance of 120u H. It has a tolerance of 10%. This device is made with bobbin core technology. This leaded inductor has a maximum DC current of 508m A with a maximum resistance of 283m Ohm.

安富利:
Ind High Current RF Choke Bobbin Core 120uH 10% 1KHz Ferrite 508mA AXL

Chip1Stop:
Ind High Current RF Choke Bobbin Core 120uH 10% 1KHz Ferrite 508mA AXL

TME:
Inductor: axial; THT; 120uH; 508mA; 283mΩ; Ø6.73x17.78mm; ±10%

Verical:
High Current RF Choke Bobbin Core 120uH 10% 1KHz Ferrite 0.7A 0.3Ohm DCR AXL

Newark:
# BOURNS JW MILLER  5800-121-RC  Choke, High Current, 120 µH, 508 mA, 0.283 ohm, ± 10%, 5800 Series

MASTER:
High Current RF Choke Bobbin Core 120uH 10% 1KHz Ferrite 700mA 300mOhm DCR AXL

Electro Sonic:
High Current RF Choke Bobbin Core 120uH 10% 1KHz Ferrite 700mA 300mOhm DCR AXL
