HEX 2输入或驱动程序 HEX 2-INPUT OR DRIVERS
description
These devices contain six independent 2-input OR drivers. They perform the Boolean functions Y = A + B or Y = A • B in positive logic.
The SN54ALS832A and SN54AS832B are characterized for operation over the full military temperature range of –55°C to 125°C. The SN74ALS832A and SN74AS832B are characterized for operation from 0°C to 70°C.
• High Capacitive-Drive Capability
• ′ALS832A Has Typical Delay Time of 4.8 ns CL = 50 pF and Typical Power Dissipation of 4.5 mW Per Gate
• ′AS832B Has Typical Delay Time of 3.2 ns CL = 50 pF and Typical Power Dissipation of Less Than 13 mW Per Gate
• Package Options Include Plastic
Small-Outline DW Packages, Ceramic Chip Carriers FK, and Standard Plastic N and Ceramic J 300-mil DIPs
