5-5179009-3

AMP FROM TE CONNECTIVITY  5-5179009-3  板至板连接, FH系列, 80 触点, 插座, 0.8 mm, 焊接, 2 排

80 位置 插座，外罩触点 表面贴装型 镀金

得捷:
CONN RCPT 80POS SMD GOLD

立创商城:
5-5179009-3

e络盟:
AMP FROM TE CONNECTIVITY  5-5179009-3  板至板连接, FH系列, 80 触点, 插座, 0.8 mm, 焊接, 2 排

艾睿:
Reduce the possibility of accidentally shorting pins when using a printed circuit board with this fine pitch connector 5-5179009-3 header connector from TE Connectivity. This RCP connector&s;s 80 contacts that are made out of beryllium copper and plated with gold over nickel. This is a 2-row connector. It has a maximum voltage rating of 100 VAC. Its pitch is 0.8 mm. It has a straight body orientation. It has a receptacle type gender. This device has a maximum current rating of 0.5 A/contact. In order to ensure parts aren&s;t damaged by bulk packaging, this product comes in tube packaging to add a little more protection by storing the loose parts in an outer tube. 5-5179009-3 is housed in natural thermoplastic. This connector has an operating temperature of -40 to 85 °C. This product is 37.8 mm long, 7.75 mm tall and 6.8 mm deep. It uses the solder termination method.

安富利:
Conn Fine Pitch Connector RCP 80 POS 0.8mm Solder ST SMD Tube

Verical:
Conn Fine Pitch Connector RCP 80 POS 0.8mm Solder ST SMD Tube

Newark:
# AMP - TE CONNECTIVITY  5-5179009-3  Board-To-Board Connector, 0.8 mm, 80 Contacts, Receptacle, FH Series, Surface Mount, 2 Rows

MASTER:
RCEPTACLE ASSEMBLY 9H TYPE FOR FH 0.8mm PITCH B-T-B CONNECTOR

Powell:
.4mm, .5mm, .6mm, .8mm, 1mm, Fine Pitch, Surface Mount, Stacking Bd-to-Bd Connectors

Electro Sonic:
0.8FH,R09H.5,080,08/Sn,TU
