51AAA-B28-D18L

Res Conductive Plastic POT 50KΩ 20% 0.25W1/4W 1Elec/1MechTurn 6.35mm 31.12 X 12.5 X 13.25mm Pin Panel Mount/Through Hole

Model 51 is a 1⁄2" square, single-turn, modular panel control that gives the versatility of larger modular panel controls in a small package. Metal bushing and metal shaft are standard.

.

*Shaft Type:** **B24:** 1⁄4" Dia. × 3⁄4", **B28:** 1⁄4" Dia. × 7⁄8", **E24:** 1⁄8" Dia. × 3⁄4" and **E28:** 1⁄8" Dia. × 7⁄8".

**Features:**

* Operating Temperature Range: +1°C to +125°C

* Tracking: 3 dB

Allied Electronics:
PANEL CONTROL - 1/2" 12.5mm SQ 1-TURN

TME:
Potentiometer: shaft; 500mW; 50kΩ; ±20%; Leads: for PCB; 290°; IP64

Verical:
Res Conductive Plastic POT 50K Ohm 20% 0.25W1/4W 1Elec/1MechTurn 6.35mm 31.12 X 12.5 X 13.25mm Pin Panel Mount/Through Hole

MASTER:
Res Conductive Plastic POT 50K Ohm 20% 0.25W1/4W 1Elec/1MechTurn 6.35mm 31.12 X 12.5 X 13.25mm Pin Panel Mount/Through Hole

Electro Sonic:
Res Conductive Plastic POT 50K Ohm 20% 0.25W1/4W 1Elec/1MechTurn 6.35mm 31.12 X 12.5 X 13.25mm Pin Panel Mount/Through Hole
