针座
针座 通孔 14 位置 0.100"(2.54mm)
得捷:
CONN HEADER VERT 14POS 2.54MM
立创商城:
2.54mm 2x7P 直插 方针
艾睿:
Reduce safety concerns with this unshrouded 5-146253-7 header connector from TE Connectivity which will reduce the possibility of accidentally shorting pins when a printed circuit board is being used. This HDR connector&s;s 14 contacts that are made out of phosphor bronze and plated with gold over nickel. It has a header type gender. It has a straight body orientation. Its pitch is 2.54 mm. This is a 2-row connector. This device has a maximum current rating of 3 A/contact. It uses the solder termination method. This connector has an operating temperature of -65 to 105 °C. 5-146253-7 is housed in black thermoplastic. This product is 17.37 mm long, 10.37 mm tall and 4.88 mm deep.
安富利:
Conn Unshrouded Header HDR 14 POS 2.54mm Solder ST Thru-Hole
Chip1Stop:
Conn Unshrouded Header HDR 14 POS 2.54mm Solder ST Thru-Hole
Verical:
Conn Unshrouded Header HDR 14 POS 2.54mm Solder ST Top Entry Thru-Hole Carton
MASTER:
HEADER ASSEMBLY, MOD II, BREAKAWAY, DOUBLE ROW,
Powell:
.100 inch AMPMODU Headers
Electro Sonic:
14 MODII HDR DRST B/A .100CL LF
触点数 14
触点电镀 Gold, Tin over Nickel
额定电流 3 A
绝缘电阻 5000 MΩ
排数 2
方向 Vertical
易燃性等级 UL 94 V-0
针脚数 14
额定电流Max 3A/触头
工作温度Max 105 ℃
工作温度Min -65 ℃
额定电压Max 30 VAC
安装方式 Through Hole
封装 ThroughHole
引脚间距 2.54 mm
长度 17.37 mm
宽度 4.88 mm
高度 10.37 mm
封装 ThroughHole
引脚间距 2.54 mm
外壳颜色 Black
颜色 Black
触点材质 Phosphor Bronze
工作温度 -65℃ ~ 105℃
外壳材质 Thermoplastic
产品生命周期 Active
包装方式 Bulk
制造应用 -
RoHS标准 RoHS Compliant
含铅标准 Lead Free
ELV标准 Compliant
ECCN代码 EAR99
HTS代码 8536694040
