EXCALIBUR低噪声高速JFET输入运算放大器 EXCALIBUR LOW-NOISE HIGH-SPEED JFET-INPUT OPERATIONAL AMPLIFIERS
description
The TLE207x series of JFET-input operational amplifiers more than double the bandwidth and triple the slew rate of the TL07x and TL08x families of BiFET operational amplifiers. Texas Instruments Excalibur process yields a typical noise floor of 11.6 nV/√Hz, 17-nV/√Hzensured maximum, offering immediate improvement in noise-sensitive circuits designed using the TL07x. The TLE207x also has wider supply voltage rails, increasing the dynamic signal range for BiFET circuits to ±19 V. On-chip zener trimming of offset voltage yields precision grades for greater accuracy in dc-coupled applications.
Direct Upgrades to TL05x, TL07x, and TL08x BiFET Operational Amplifiers
Greater Than 2×Bandwidth 10 MHz and 3×Slew Rate 45 V/μs Than TL07x
Ensured Maximum Noise Floor 17 nV/√Hz
On-Chip Offset Voltage Trimming for Improved DC Performance
Wider Supply Rails Increase Dynamic Signal Range to ±19 V
