Conn Unshrouded Header HDR 8POS 2.54mm Solder ST Thru-Hole Automotive Carton
针座 通孔 8 位置 0.100"(2.54mm)
得捷:
CONN HEADER VERT 8POS 2.54MM
贸泽:
Headers & Wire Housings 08 MODII HDR SRST B/A .100CL
艾睿:
Use this unshrouded 5-146274-8 header connector from TE Connectivity where IDC ribbon cables are used. This HDR connector&s;s 8 contacts that are made out of phosphor bronze and plated with tin over nickel. This is a 1-row connector. It has a header type gender. It has a maximum voltage rating of 250 VAC. It has a straight body orientation. Its pitch is 2.54 mm. This device has a maximum current rating of 3 A/contact. This product is 19.91 mm long, 10.37 mm tall and 2.34 mm deep. It uses the solder termination method. 5-146274-8 is housed in black liquid crystal polymer. This connector has an operating temperature of -65 to 105 °C.
Powell:
.100 inch AMPMODU Headers
Electro Sonic:
08 MODII HDR SRST B/A .100CL
触点数 8
触点电镀 Tin, Tin over Nickel
额定电流 3 A
排数 1
方向 Vertical
易燃性等级 UL 94 V-0
针脚数 8
额定电流Max 3A/触头
工作温度Max 105 ℃
工作温度Min -65 ℃
额定电压Max 250 VAC
安装方式 Through Hole
高度 10.37 mm
外壳颜色 Black
触点材质 Phosphor Bronze
工作温度 -65℃ ~ 105℃
产品生命周期 Active
包装方式 Bulk
制造应用 -
RoHS标准 RoHS Compliant
含铅标准 Lead Free
ELV标准 Compliant
