62JA200概述
Res Wirewound POT 200Ω 5% 2W 10Elec/10MechTurn 6.32mm 22.23 X 25.4 X 68.26mm Solder Lug Panel Mount
62 Series 10-Turn Potentiometer — Type 62JA
3⁄8" Plain bushing.- .
- *Slotted shaft:** 15⁄16" FMS. 100,000 shaft revolutions life. Sleeve bearings. **Functional Output:** Linear. **Absolute Linearity:** ±0.25%. **Power Dissipation:** 2 Watts at 25°C. **Stop Torque:** 50 Oz.-in. **Effective Rotation:** 360°.
得捷:
POT 200 OHM 2W WIREWOUND LINEAR
Allied Electronics:
Potentiometer, Wirewound, Res 200 Ohms, Panel, 10 Turns, Pwr-Rtg 2 W, Linear
Powell:
RESISTIVE & OPTICAL
Electro Sonic:
Res Wirewound POT 200 Ohm 5% 2W 10Elec/10MechTurn 6.32mm 22.23 X 25.4 X 68.26mm Solder Lug Panel Mount
62JA200中文资料参数规格
技术参数
容差 ±5 %
额定功率 2 W
电阻 200 Ω
工作温度Max 120 ℃
工作温度Min -40 ℃
封装参数
安装方式 Solder Lug, Panel
封装 Round - 0.875" Dia x 1.563" H 22.23mm x 39.69mm
外形尺寸
直径 22.4 mm
封装 Round - 0.875" Dia x 1.563" H 22.23mm x 39.69mm
物理参数
工作温度 -55℃ ~ 85℃
温度系数 ±20 ppm/℃
其他
产品生命周期 Obsolete
包装方式 Bulk
符合标准
RoHS标准 RoHS Compliant
含铅标准 Lead Free
在线购买62JA200
型号： 62JA200
制造商：
Honeywell
霍尼韦尔
描述：Res Wirewound POT 200Ω 5% 2W 10Elec/10MechTurn 6.32mm 22.23 X 25.4 X 68.26mm Solder Lug Panel Mount
