640502-4

Conn Rectangular PIN 12POS 4.19mm Solder ST Thru-Hole Bag

针座连接器 通孔 12 位置 0.165"（4.20mm）

得捷:
CONN HEADER VERT 12POS 4.2MM

艾睿:
Ensure a strong, reliable connection between two electronic components using TE Connectivity&s;s 640502-4 USB connector. This RCP connector&s;s 12 contacts that are made out of phosphor bronze and plated with gold over nickel. Its pitch is 4.19 mm. It has a straight body orientation. It has a maximum voltage rating of 250 VAC. It has a receptacle type gender. This is a 4-row connector. This device has a maximum current rating of 9 A/contact. 640502-4 is housed in nylon. This harting connector has an operating temperature of -55 to 105 °C. It uses the solder termination method. This product is 23.36 mm long and 20.95 mm.

Verical:
Conn HDR, 12P MR HDR ASSY V0 RED

Powell:
.165" Centerline, 250 V, 9 A max.

Electro Sonic:
12P MR HDR ASSY V0 RED
