6-146250-0

Conn Unshrouded Header HDR 20POS 2.54mm Solder ST Thru-Hole

20 MODII HDR DRST B/A .100CL

Product Highlights

Header

Header Type = Breakaway

Number of Rows = Dual

Number of Positions = 20

Mating Post Length = 8.08 mm

得捷:
CONN HEADER VERT 20POS 2.54MM

艾睿:
Protect your printed circuit boards from accidental damages with TE Connectivity&s;s unshrouded 6-146250-0 header connector. This HDR connector&s;s 20 contacts that are made out of phosphor bronze and plated with matte tin over nickel. It has a straight body orientation. It has a header type gender. Its pitch is 2.54 mm. This is a 2-row connector. This device has a maximum current rating of 3 A/contact. It uses the solder termination method. 6-146250-0 is housed in black thermoplastic. This product is 24.99 mm long, 10.37 mm tall and 4.88 mm deep. This connector has an operating temperature of -65 to 105 °C.

Chip1Stop:
Conn Unshrouded Header HDR 20 POS 2.54mm Solder ST Thru-Hole

Verical:
Conn Unshrouded Header HDR 20 POS 2.54mm Solder ST Thru-Hole Carton

Newark:
# AMP - TE CONNECTIVITY  6-146250-0  20 MODII HDR DRST B/A .100CL New

Powell:
.100 inch AMPMODU Headers

Electro Sonic:
20 MODII HDR DRST B/A .100CL
