6-146278-4

Conn Unshrouded Header HDR 14POS 2.54mm Solder ST Thru-Hole

针座 通孔 14 位置 0.100"（2.54mm）

得捷:
CONN HEADER VERT 14POS 2.54MM

艾睿:
Safety is an important concern when designing electronic devices. TE Connectivity&s;s unshrouded 6-146278-4 header connector helps protect your equipment from accidental shortages. This HDR connector&s;s 14 contacts that are made out of phosphor bronze and plated with tin over nickel. This is a 1-row connector. It has a header type gender. It has a straight body orientation. Its pitch is 2.54 mm. This device has a maximum current rating of 3 A/contact. 6-146278-4 is housed in black liquid crystal polymer. This connector has an operating temperature of -65 to 105 °C. It uses the solder termination method. This product is 35.15 mm long, 8.13 mm tall and 2.34 mm deep.

安富利:
Conn Unshrouded Header HDR 14 POS 2.54mm Solder ST Thru-Hole

富昌:
MOD II 14 Position Through Hole Single Row Vertical 0.1 inch Breakaway Header

Chip1Stop:
Conn Unshrouded Header HDR 14 POS 2.54mm Solder ST Thru-Hole

Verical:
Conn Unshrouded Header HDR 14 POS 2.54mm Solder ST Thru-Hole Automotive Carton

MASTER:
HEADER ASSEMBLY, MOD II, BREAKAWAY, SINGLE ROW, HIGH TEMPERATURE,

Powell:
.100 inch AMPMODU Headers

Electro Sonic:
14 MODII HDR SRST B/A .100CL
