6-146257-3

Conn Unshrouded Header HDR 26POS 2.54mm Solder ST Thru-Hole

Connector Header Through Hole 26 position 0.100" 2.54mm

得捷:
CONN HEADER VERT 26POS 2.54MM

贸泽:
Headers & Wire Housings HDR VT 2X13P .1 230/110 30AU

艾睿:
Mounting this unshrouded 6-146257-3 header connector from TE Connectivity to your printed circuit board can help you support multiple physical configuration options. This HDR connector&s;s 26 contacts that are made out of phosphor bronze and plated with gold over nickel. Its pitch is 2.54 mm. It has a header type gender. This is a 2-row connector. It has a straight body orientation. This device has a maximum current rating of 3 A/contact. This product is 32.61 mm long, 8.13 mm tall and 4.88 mm deep. It uses the solder termination method. This connector has an operating temperature of -65 to 105 °C. 6-146257-3 is housed in black thermoplastic.

安富利:
Conn Unshrouded Header HDR 26 POS 2.54mm Solder ST Thru-Hole

Powell:
.100 inch AMPMODU Headers

Electro Sonic:
26 MODII HDR DRST B/A .100CL L
