AMPHENOL COMMERCIAL PRODUCTS 6E17C009SAJ220 连接器, D-SUB, 直角
Conn D-Subminiature SKT 9 POS 2.74mm Solder RA Thru-Hole 9 Terminal 1 Port
e络盟:
AMPHENOL COMMERCIAL PRODUCTS 6E17C009SAJ220 连接器, D-SUB, 直角
艾睿:
This 6E17C009SAJ220 DVI connector from Amphenol is ideal for all your serial communication needs. It has a right angle body orientation. This socket type connector&s;s 9 contacts that are made out of copper alloy and plated with gold over nickel. Its pitch is 2.74 mm. This 2-row connector has a single port. 6E17C009SAJ220 is housed in thermoplastic. This device has a maximum current rating of 5 A. Its 9 terminals use the solder termination method. This DVI connector has an operating temperature of -55 to 105 °C. This product is 30.81 mm long, 12.55 mm tall and 18.85 mm deep.
Chip1Stop:
Conn D-Subminiature SKT 9 POS 2.74mm Solder RA Thru-Hole 9 Terminal 1 Port
Verical:
Conn D-Subminiature SKT 9 POS 1.37mm Solder RA Thru-Hole 9 Terminal 1 Port
Newark:
# AMPHENOL COMMERCIAL PRODUCTS 6E17C009SAJ220 Standard D Sub Connector, 9 Contacts, Receptacle, DE, 6E17 Series, Steel Body, Through Hole
MASTER:
Conn D-Subminiature SKT 9 POS 2.74mm Solder RA Thru-Hole 9 Terminal 1 Port
Online Components:
Conn D-Subminiature SKT 9 POS 2.74mm Solder RA Thru-Hole 9 Terminal 1 Port
Electro Sonic:
Conn D-Subminiature SKT 9 POS 2.74mm Solder RA Thru-Hole 9 Terminal 1 Port
