6-176146-6概述

TE Connectivity 187 系列连接器外壳广泛的 187 系列连接器插头和插座式外壳### TE Connectivity Econoseal 连接器系统设计上达到汽车工业对可靠密封连接器的严格要求。所有连接器均设计用于薄壁未辐照 PVC 电缆 尽管最初设计用于汽车应用,Econoseal III 亦可用于需要可靠密封连接器的任何行业。

187 系列外壳

广泛的 187 系列连接器插头和插座式外壳


得捷:
CONN RCPT HSG 0.187 2POS GRAY


欧时:
TE Connectivity .187 系列 系列 2路 电缆安装 灰色 公 外壳 6-176146-6


立创商城:
7.9mm 1x2P


贸泽:
汽车连接器 .187 PLUG 2P GRAY HSG ASSEM


艾睿:
If you are in need of a direct board to socket connection, look no further than this 6-176146-6 discrete wire housing from TE Connectivity. This PL connector has 2 PL contacts. Its pitch is 7.9 mm. This is a 1-row connector. It has a plug type gender. It has a straight body orientation. The component will be shipped in tray format. This product is 27.6 mm long, 27.5 mm tall and 31.6 mm deep. Its wire is 12-20 AWG. 6-176146-6 is housed in light gray polybutylene terephthalate.


Allied Electronics:
.187 Series Series, 2 Way Cable Mount Plug Housing


安富利:
Conn Housing PL 2 POS 7.9mm Crimp ST Cable Mount


Chip1Stop:
Conn Housing PL 2 POS 7.9mm Crimp ST Cable Mount


AMEYA360:
TE Connectivity 1行 2路 灰色 公 电缆安装 外壳


6-176146-6中文资料参数规格
技术参数

触点数 2

极性 Female

额定电流 25 A

排数 1

易燃性等级 UL 94 V-2

针脚数 2

工作温度Max 105 ℃

工作温度Min -30 ℃

额定电压Max 13 VDC

封装参数

封装 -

外形尺寸

长度 27.6 mm

宽度 27.6 mm

高度 27.5 mm

封装 -

物理参数

外壳颜色 Light Gray

颜色 Gray

材质 Plastic

工作温度 -30℃ ~ 105℃

其他

产品生命周期 Active

包装方式 Tray

制造应用 Signal

符合标准

RoHS标准 RoHS Compliant

含铅标准 Lead Free

ELV标准 Compliant

数据手册

在线购买6-176146-6
型号: 6-176146-6
描述:TE Connectivity 187 系列连接器外壳 广泛的 187 系列连接器插头和插座式外壳 ### TE Connectivity Econoseal 连接器系统 设计上达到汽车工业对可靠密封连接器的严格要求。 所有连接器均设计用于薄壁未辐照 PVC 电缆 尽管最初设计用于汽车应用,Econoseal III 亦可用于需要可靠密封连接器的任何行业。
