6R3S43X107MV4E

JOHANSON DIELECTRICS  6R3S43X107MV4E  多层陶瓷电容器, 表面贴装, 100 µF, ± 20%, X5R, 6.3 V, 1812 [4532 公制]

The is a TANCERAM® Chip Capacitor with X5R dielectric and 100% tin-plated matte nickel barrier termination. The chip capacitor can replace tantalum capacitor in many applications and offer several key advantages over traditional tantalums. Because TANCERAM® capacitor exhibit extremely low ESR, equivalent circuit performance can often be achieved using considerably lower capacitance values. Low DC leakage reduces current drain, extending the battery life of portable products. TANCERAM® high DC breakdown voltage ratings offer improved reliability and eliminate large voltage de-rating common when designing with tantalums. It is suitable for switching power supply smoothing input/output, DC/DC converter smoothing input/output, backlighting inverters and general digital circuits.

.

Low ESR

.

High surge voltage

.

Reduced chip size

.

High insulation resistance

.

Low DC leakage

.

Non-polarized devices

.

Improved reliability

.

High ripple current
