6-534998-2

24Position 2.54mm Solder Straight Through Hole Connector Socket

24 位置 插座 通孔

得捷:
CONN RCPT 24POS 0.1 GOLD PCB

立创商城:
2.54mm

艾睿:
Use this socket strip 6-534998-2 header connector from TE Connectivity where IDC ribbon cables are used. This RCP connector&s;s 24 contacts that are made out of phosphor bronze and plated with gold over nickel. Its pitch is 2.54 mm. This is a 2-row connector. It has a straight body orientation. It has a receptacle type gender. This device has a maximum current rating of 2 A/contact. This connector has an operating temperature of -65 to 105 °C. It uses the solder termination method. This product is 30.48 mm long, 6.73 mm tall and 5.03 mm deep. 6-534998-2 is housed in black polychlorinated terphenyl.

安富利:
Conn Socket Strip RCP 24 POS 2.54mm Solder ST Thru-Hole Gang of Tubes

Chip1Stop:
Conn Socket Strip RCP 24 POS 2.54mm Solder ST Thru-Hole Gang of Tubes

Verical:
Conn Socket Strip F 24 POS 2.54mm Solder ST Top Entry Thru-Hole Box/Tube

Newark:
# TE CONNECTIVITY  6-534998-2  Board-To-Board Connector, 2.54 mm, 24 Contacts, Receptacle, AMPMODU Mod IV Series, Through Hole

MASTER:
RECEPTACLE ASSEMBLY, MOD IV, DOUBLE ROW, DUAL ENTRY, .100X.100CL, VERTICAL MOUNT, AMPMODU

Powell:
.100 inch AMPMODU Receptacles

Online Components:
24 MODIV VRT DR CE 100/125

Electro Sonic:
24 MODIV VRT DR CE 100/125
