Conn Barrier Strip 24POS 9.53mm Solder ST Thru-Hole 5A/Contact
24 Circuit 0.375" 9.53mm Barrier Block Connector, Screws
得捷:
CONN BARRIER STRP 24CIRC 0.375"
艾睿:
Conn Barrier Strip 24 POS 9.53mm Solder ST Thru-Hole 5A/Contact Package
Verical:
Conn Barrier Strip 24 POS 9.53mm Solder ST Thru-Hole 5A/Contact Package
MASTER:
Conn Barrier Strip 24 POS 9.53mm Solder ST Thru-Hole 5A/Contact Package
Electro Sonic:
Conn Barrier Strip 24 POS 9.53mm Solder ST Thru-Hole 5A/Contact Package
触点数 24
线规 12AWG ~ 22AWG
额定电流 25 A
排数 1
电路数 24
易燃性等级 UL 94 V-0
额定电流Max 5A/触头
工作温度Max 105 ℃
额定电压Max 600 V
额定电压 300 V
工作电压Max 600 V
安装方式 Through Hole
高度 15.88 mm
外壳颜色 Black
颜色 Black
触点材质 Copper Alloy, Steel
工作温度 105 ℃
外壳材质 Thermoplastic
产品生命周期 Active
RoHS标准 RoHS Compliant
含铅标准 Lead Free
ELV标准 Compliant
ECCN代码 EAR99
HTS代码 8536694040
