74LVC 系列，NXP低电压 CMOS 逻辑 工作电压：1.2 至 3.6 兼容性：输入 LVTTL/TTL、输出 LVCMOS ### 74LVC 系列
General description
The 74LVC16244A; 74LVCH16244A are 16-bit non-inverting buffer/line drivers with 3-state bus compatible outputs. The device can be used as four 4-bit buffers, two 8-bit buffers or one 16-bit buffer.
Features and benefits
5 V tolerant inputs/outputs for interfacing with 5 V logic
Wide supply voltage range from 1.2 V to 3.6 V
CMOS low power consumption
Multibyte flow-through standard pin-out architecture
Low inductance multiple power and ground pins for minimum noise and ground bounce
Direct interface with TTL levels
High-impedance when VCC=0V
All data inputs have bus hold. 74LVCH16244A only
Complies with JEDEC standard:
JESD8-7A 1.65 V to 1.95 V
JESD8-5A 2.3 V to 2.7 V
JESD8-C/JESD36 2.7 V to 3.6 V
ESD protection:
HBM JESD22-A114F exceeds 2000 V
MM JESD22-A115-B exceeds 200 V
CDM JESD22-C101E exceeds 1000 V
Specified from -40°C to +85°C and -40°C to +125°C
