Switch Toggle ON OFF Mom DPDT Round Lever PC Pins 20VAC 20VDC 0.4VA PC Mount with Bracket
Miniature Toggle Switch
立创商城:
7207MD9ABE
得捷:
SWITCH TOGGLE DPDT 0.4VA 20V
贸泽:
Toggle Switches Toggle DPDT On-Off-Mom
艾睿:
The 7207MD9ABE toggle switch from C&a;K Components allows you to control the status of your project. It has a DPDT configuration. This toggle switch has a minimum operating temperature of -30 °C and a maximum of 85 °C. The 7207MD9ABE toggle switch has a PC pin termination style. The maximum AC voltage rating is 20 VAC and the maximum DC voltage rating is 20 VDC. This product is 12.7 mm long, 11.43 mm tall and 31.12 mm deep.
Chip1Stop:
Switch Toggle ON OFF Mom DPDT Round Lever PC Pins 20VAC 20VDC 0.4VA PC Mount with Bracket
Verical:
Switch Toggle ON OFF Mom DPDT Round Lever PC Pins 20VAC 20VDC 0.4VA PC Mount with Bracket Medical Bulk
Newark:
# C & K COMPONENTS 7207MD9ABE Toggle Switch, 7000 Series, DPDT, On-Off-On, Through Hole, 20 V
MASTER:
Miniature Toggle Switch
Electro Sonic:
Miniature Toggle Switch
额定电压DC 20 V
额定电压AC 20 V
排数 2
额定功率 0.4 VA
触点类型 2PDT
工作温度Max 85 ℃
工作温度Min -30 ℃
额定电压DC Max 20 V
额定电压AC Max 20 V
接触电阻Max <10 mΩ
安装方式 Through Hole
封装 -
长度 12.7 mm
高度 11.43 mm
封装 -
触点材质 Copper Alloy
工作温度 -30℃ ~ 85℃
产品生命周期 40000 Cycles
包装方式 Bulk
RoHS标准 RoHS Compliant
含铅标准 Lead Free
ECCN代码 EAR99
HTS代码 8536509040
