7813J-1-023E

BOURNS  7813J-1-023E  旋转开关, 7813J系列, 不发光, 245 °, 100 mA, 100 mA

DIP SPDT 位置 表面贴装型 用于工具旋转 触动器 100mA 16VAC/DC

得捷:
SWITCH ROTARY DIP SPDT 100MA 16V

贸泽:
Rotary Switches 16volt SPDT 3mm 2000 cycle

e络盟:
旋转开关, 2路, 1位, 245 °, 100 mA, 7813J系列

艾睿:
If you need more than just two switch positions, look no further, this 7813J-1-023E rotary switch from Bourns will handle just that. It has a SPDT configuration. This device has a maximum current rating of 0.1. This rotary limit switch has an operating temperature range of -55 °C to 125 °C. The 7813J-1-023E rotary limit switch has a j-bend termination style. This product is 3.2 mm long, 2.2 mm tall and 3.5 mm deep. The maximum AC voltage rating is 16 VAC and the maximum DC voltage rating is 16 VDC.

Allied Electronics:
SWITCH 3MM SQ SPDT 2000LIFE 16V

安富利:
Switch Rotary SPDT 2 Flush Screwdriver J-Bend 0.1A 16VAC 16VDC Embossed T/R

Chip1Stop:
Switch Rotary SPDT 2 Flush Screwdriver J-Bend 0.1A 16VAC 16VDC T/R

Verical:
Switch DIP N.O./N.C. SPDT 2 Flush Screwdriver 0.1A 16VAC 16VDC J-Bend 2000Cycles SMD T/R

Newark:
# BOURNS  7813J-1-023E  SWITCH, SPDT, SMD, 3MM

MASTER:
Switch DIP SPDT 2 Flush Screwdriver 0.1A 16VAC 16VDC J-Bend 2000Cycles SMD T/R

Online Components:
Switch Rotary SPDT 2 Flush Screwdriver J-Bend 0.1A 16VAC 16VDC T/R

Electro Sonic:
Switch DIP SPDT 2 Flush Screwdriver 0.1A 16VAC 16VDC J-Bend 2000Cycles SMD T/R
