709176001511006

AVX INTERCONNECT  709176001511006  金属触芯, IDC, 1路, 20AWG

The 9176-500 series Contact And Cap accepts 18 to 24AWG wires with an insulation diameter ranging from 1.1 to 2.1mm. These dual beam contacts support a 10A current rating with a large SMT solder base to provide maximum stability on the PCB. The optional locking strain relief cap acts as the termination tool for severe vibration applications.

.

IDC contact is supplied in T and R pockets for standard SMT placement

.

IDC contact provides a gas-tight connection to the PCB for long term reliability

.

Optional termination cap provides additional strain relief for severe environments

.

Tested to automotive levels on shock, vibration and temperature cycling for reliability

.

Reduced total applied cost versus solder or crimp processes

.

10A Current rating per contact

.

UL94V-0 Flammability

.

3 Cycles durability

.

-40 to 125°C Operating temperature
