FAIRCHILD SEMICONDUCTOR  74AC245SC  缓冲器, 非反相, 3态, 8门, 1输入, 2V至6V, SOIC-20

The is an octal Bidirectional Transceiver with 3-state inputs/outputs and is intended for bus-oriented applications. Current sinking capability is 24mA at both the A and B ports. The transmit/receive T/R input determines the direction of data flow through the bidirectional transceiver. Transmit active-HIGH enables data from A ports to B ports, receive active-LOW enables data from B ports to A ports. The output enables input, when HIGH disables both A and B ports by placing them in a HIGH Z condition.

.

ICC and IOZ reduced by 50%

.

Non-inverting buffers

.

Bidirectional data path

.

A and B Outputs source/sink 24mA
