74FST3257MNTWG

2:1多路复用器/多路解复用器总线开关

The 74FST3257 is a quad 2:1, high performance multiplexer/demultiplexer bus switch. The device is CMOS TTL compatible when operating between 4 and 5.5 Volts. The device exhibits extremely low R and adds nearly zero propagation delay. The device adds no noise or ground bounce to the system.

Features

---

 |

.

RON < 4 Ω Typical

.

Less Than 0.25 ns-Max Delay Through Switch

.

Nearly Zero Standby Current

.

No Circuit Bounce

.

Control Inputs are TTL/CMOS Compatible

.

Pin-For-Pin Compatible With QS3257, FST3257, CBT3257

.

All Popular Packages: QSOP-16, TSSOP-16, SOIC-16

.

Pb-Free Packages are Available
