796682-4

Conn Eurostyle Block 4POS 5mm Solder ST Thru-Hole 17.5A/Contact

4 接线板 - 线至板 水平，带板 0.197"（5.00mm） 通孔

得捷:
TERM BLK 4POS SIDE ENTRY 5MM PCB

贸泽:
Fixed Terminal Blocks TERMI-BLOK PCB

艾睿:
This eurostyle block 796682-4 PCB terminal block developed by TE Connectivity will mend different gage wires together. It has a straight body orientation. This is a 1-row connector. It has a maximum voltage rating of 300 VAC. Its pitch is 5 mm. 796682-4 is housed in polyamide 6/6. This device has a maximum current rating of 17.5 A/contact. It uses the solder termination method. This quick disconnect terminal has an operating temperature of -40 to 105 °C. This product is 20.5 mm long, 15.5 mm tall and 9 mm deep. Its wire is 12-30 AWG.

安富利:
Conn Terminal Block 4 POS 5mm Solder ST Thru-Hole 17.5A/Contact

Powell:
Terminal Block Connectors

Win Source:
TERM BLK 4POS SIDE ENTRY 5MM PCB / 4 Position Wire to Board Terminal Block Horizontal with Board 0.197" 5.00mm Through Hole
