Switch Rocker ON None Mom SPDT Solder Lug Rocker 5A 250VAC 28VDC
Miniature Rocker & Lever Handle Switch
立创商城:
7108J51ZQE22
艾睿:
Switch Rocker ON None Mom SPDT Solder Lug Rocker 5A 250VAC 28VDC Bulk
Allied Electronics:
Switch Rocker ON None Mom SPDT Solder Lug Rocker 5
Chip1Stop:
Switch Rocker ON None Mom SPDT Solder Lug Rocker 5A 250VAC 28VDC
Verical:
Switch Rocker ON None Mom SPDT Solder Lug Rocker 5A 250VAC 28VDC Medical Bulk
MASTER:
Miniature Rocker & Lever Handle Switch
Electro Sonic:
Miniature Rocker & Lever Handle Switch
触点电镀 Silver
额定电压DC 28 V
接触器类型 Rocker
额定电压AC 120 V
额定电流 5A AC, 5A DC
排数 1
触点类型 SPDT
额定电流Max 5A @120VAC, 28VDC
工作温度Max 85 ℃
工作温度Min -30 ℃
额定电压DC Max 28 V
额定电压AC Max 250 V
接触电阻Max <10 mΩ
安装方式 Quick Connect, PCB
封装 -
长度 19.43 mm
高度 25.4 mm
封装 -
颜色 Black
触点材质 Coin Silver
产品生命周期 40000 Cycles
包装方式 Bulk
RoHS标准 RoHS Compliant
含铅标准 Lead Free
ECCN代码 EAR99
HTS代码 8536509040
